Specification:
Packaging capacity: 20-120 bags/min (depending on material properties and bag size)
Fillable capacity: 0.5-50cc (150cc)
Package size: Width: 30-110mm
Length: 40-200 mm
Number of sealing roller sections: 3
Packaging film width: 60-210mm
Maximum film diameter: 400mm
Packaging film tube diameter: 75mm
Depth: 900 mm, Width: 1600 mm, Height: 1950 mm (including mixing height: 2550 mm)
Machine weight: 500 kg
Use of electricity：
Motor 1 power: single-phase 220V,400W
Motor power: 220V single-phase, 400W
Motor power rating: 400W single-phase 220V
Motor power: 400W single-phase 220V
Motor power rating: 400W single-phase 220V
Servo piston pump: Single-phase 220V 400W (optional)
Servo magnetic pump: Single-phase 220V 400W (optional)
Servo centrifugal pump: Single-phase 220V 750W (optional)
Servo film release: single-phase 220V 750W (optional)
Motor power: Single-phase 220V 400W (optional)
Heater power: 2-phase 380V 600W four-wire
Stirrer motor power: 3-phase 380V,370W (optional)
Vertical stirring motor power: 3-phase 380V 180W (optional)
Centrifugal pump motor power: 3-phase 380V,180W (optional)
Total power: 4.6 kW-7.83 kW
